** When you order this pump, you will receive the updated version, AR30-SP**

Hypro/Pentair no longer distributes the 9910 series, but pumps and parts remain available with updated factory labeling.

Hypro medium pressure diaphragm pumps are recommended for spraying herbicides, pesticides, liquid fertilizers, and many other hard-to-handle fluids. Low-cost maintenance and almost wear-free operation make these pumps ideal for a wide variety of spraying jobs. Pressure and output are designed for optimum performance of small to medium-sized sprayers. Hypro medium pressure diaphragm pumps can be adapted for male 1-3/8" splined shaft, female 1-3/8" splined shaft, 1" solid shaft, or gear reduction drive options. See page 2 of manual for drive options.

Download Product Manual

• Max flow: 9.6 gpm
• Max pressure: 580 psi
• Max rpm: 580
• Port sizes: 1" HB inlet, 1/2" HB outlet
• Shaft: Flanged for shaft kit or gearbox
• Pump shaft rotation: CW and CCW
• Diaphragms: 2, semi-hydraulic BlueFlex, Desmopan® and Buna available
• Housing: Anodized aluminum
• Recommended pressure regulator: 9910-GS40GI
• Recommended gearbox: 9910-KIT1640 (AR1636) or AR1666 (updated pinion design) with 3/4" hollow shaft for mounting on 5 to 6.5 hp engines
• Max fluid temperature: 140°F
• Weight: 23 lbs
