Hypro Pump - 7700XL

Hypro Pump - 7700XL

Brand:
Hypro
Weight:
11.0 lb
Item #
7700XL

$763.60
$763.60 List Price: $1,388.37

Earn 2,291 points with this purchase.

See Details

View full details

Product Overview

Hypro Roller Pump

Model: 7700XL

Hypro roller pumps are designed for agricultural and industrial spraying and transfer of a variety of fluids. These include insecticides, herbicides, emulsives, aromatic solvents, liquid fertilizers and many other liquids.

The economical rotary-action roller principle requires no check valves while providing positive displacement characteristics with less friction and lower starting torque than other pumps. Ready for use with Roundup®

Resources

Download Product Manual

Features

  • Max flow: 22.1 GPM
  • Max pressure: 200 PSI
  • Max RPM: 800
  • Port sizes: ¾" FNPT
  • Pump shaft rotation: CCW
  • Housing: Silvercast
  • Rotor: Silvercast
  • Roller material: Super Roller Standars
  • Shaft seals: Viton, Poly and Teflon available
  • Roller quantity: 7

  • Shaft: 15/16" solid stainless steel

Parts breakdown

Diagram

Diagram parts

Parts list

  • Bearing Cover
    • Ref No: 1
    • Part No: 23000020
    • Qty Req: 1
    Our price: $1.94 List price: $2.39
  • Main Bearing - Hypro Pumps
    • Ref No: 2
    • Part No: 20080001
    • Qty Req: 2
    Our price: $19.73 List price: $24.36
  • Viton Seal (Std.)
    • Ref No: 3
    • Part No: 21120003
    • Qty Req: 2
    Our price: $21.76 List price: $26.87
  • Buna-N Seal (Optional)
    • Ref No: 3
    • Part No: 21120001
    • Qty Req: 2
    Our price: $20.65 List price: $25.49
  • Bolt
    • Ref No: 4
    • Part No: 22100004
    • Qty Req: 6
    Our price: $1.18 List price: $1.46
  • Endplate (SilverCast) with Seal
    • Ref No: 5
    • Part No: 02007700X
    • Qty Req: 1
    Our price: $380.15 List price: $453.44
  • O-Ring Gasket for Endplate
    • Ref No: 6
    • Part No: 17200014
    • Qty Req: 1
    Our price: $2.92 List price: $3.60
  • Super Roller (Standard)
    • Ref No: 7
    • Part No: 10050004
    • Qty Req: 7
    Our price: $4.84 List price: $5.97
  • Buna-N Roller (Optional)
    • Ref No: 7
    • Part No: 10520004
    • Qty Req: 7
    Our price: $36.68 List price: $43.75
  • Teflon Rollers (Optional)
    • Ref No: 7
    • Part No: 10550004
    • Qty Req: 7
    Our price: $25.25 List price: $31.17
  • Body (SilverCast) with Seal
    • Ref No: 11
    • Part No: 01007700X
    • Qty Req: 1
    Our price: $592.88 List price: $707.20
  • Rotor Asembly (SilverCast)
    • Ref No: 16
    • Part No: 03007700X
    • Qty Req: 1
    Our price: $367.93 List price: $438.88
