Udor OMEGA-140/CC Diaphragm Pump

Udor OMEGA-140/CC Diaphragm Pump

Item Code:
OMEGA140CC
Weight:
100.0 lb
Manufacturer:
Udor
Our price:
$2,073.89
List price:
$3,770.70
Overview:

Choose this Udor OMEGA-140/CC Diaphragm Pump for your medium-pressure or high-pressure sprayer applications. This three-diaphragm pump features a maximum pressure rating of 700 PSI and an upper flow rate of 39 GPM. It's also tooled with a pulsation dampener and a regulator unit with an adjustable pressure controller for smooth operations. Install this in your sprayer systems used in agricultural, commercial and industrial settings.

Manufacturer Description:

OMEGA-140/CC 3-cylinder high pressure, high volume diaphragm pumps are excellent for various horticultural and agricultural spraying applications. Simplicity of design and common parts allow easy and affordable maintenance. Control valve, pulsation dampener and pressure gauge are standard. The OMEGA-140/CC is constructed of plasticized aluminum, brass and stainless steel with plasticized aluminum, brass and stainless steel liquid handling parts.

Features:

  • Max flow: 39 gpm
  • Max pressure: 700 psi
  • Includes 6005.15 control unit and dual 1-3/8" 6-spline male PTO shafts
  • Port sizes: 1-1/2" HB inlet, (2) 1/2" HB shutoff and (2) 3/4" FNPT outlet
  • Pump shaft rotation: CW and CCW
  • Diaphragms: 3, semi-hydraulic, Desmopan® standard Buna available
  • Housing: Anodized aluminum
  • Max fluid temperature: 140°F
  • Weight: 100 lbs

Parts breakdown

 Parts breakdown parts

Parts list

  • Ref No: 78
  • Part No: 000312
  • Qty Req: 1
Our price: $208.99 List price: $251.80
  • Ref No: 156
  • Part No: 000702
  • Qty Req: 2
Our price: $17.44 List price: $21.01
  • Ref No: 558
  • Part No: 020821
  • Qty Req: 1
Our price: $188.91 List price: $227.60
  • Ref No: 542
  • Part No: 020916
  • Qty Req: 1
Our price: $1,225.66 List price: $1,476.70
  • Ref No: 559
  • Part No: 020822
  • Qty Req: 1
Our price: $13.70 List price: $16.50
  • Ref No: 787
  • Part No: 030103
  • Qty Req: 3
Our price: $11.21 List price: $13.50
  • Ref No: 845
  • Part No: 030301
  • Qty Req: 8
Our price: $1.33 List price: $1.60
  • Ref No: 1034
  • Part No: 060409
  • Qty Req: 2
Our price: $7.80 List price: $9.40
  • Ref No: 1055
  • Part No: 060450
  • Qty Req: 1
Our price: $14.94 List price: $18.00
  • Ref No: 1124
  • Part No: 060845
  • Qty Req: 1
Our price: $45.24 List price: $54.50
  • Ref No: 11
  • Part No: 060816
  • Qty Req: 1
Our price: $16.93 List price: $20.40
  • Ref No: 1301
  • Part No: 090316
  • Qty Req: 1
Our price: $33.95 List price: $40.90
  • Ref No: 1365
  • Part No: 110101
  • Qty Req: 6
Our price: $3.40 List price: $4.10
  • Ref No: 1376
  • Part No: 110116
  • Qty Req: 1
Our price: $2.08 List price: $2.50
  • Ref No: 1385
  • Part No: 110132
  • Qty Req: 1
Our price: $5.73 List price: $6.90
  • Ref No: 1398
  • Part No: 110142
  • Qty Req: 1
Our price: $2.32 List price: $2.80
  • Ref No: 1409
  • Part No: 110168
  • Qty Req: 1
Our price: $4.73 List price: $5.70
  • Ref No: 1420
  • Part No: 110171
  • Qty Req: 1
Our price: $8.47 List price: $10.20
  • Ref No: 1571
  • Part No: 120508
  • Qty Req: 3
Our price: $89.72 List price: $108.10
  • Ref No: 1709
  • Part No: 600608
  • Qty Req: 6
Our price: $33.26 List price: $40.07
  • Ref No: 1778
  • Part No: 601501
  • Qty Req: 3
Our price: $199.70 List price: $240.60
  • Ref No: 18
  • Part No: 140309
  • Qty Req: 16
Our price: $1.00 List price: $1.20
  • Ref No: 1845
  • Part No: 140310
  • Qty Req: 3
Our price: $0.94 List price: $1.13
  • Ref No: 1864
  • Part No: 140345
  • Qty Req: 24
Our price: $1.00 List price: $1.20
  • Ref No: 1962
  • Part No: 150201
  • Qty Req: 3
Our price: $18.18 List price: $21.90
  • Ref No: 2046
  • Part No: 150602
  • Qty Req: 6
Our price: $1.49 List price: $1.80
  • Ref No: 2111
  • Part No: 150905
  • Qty Req: 3
Our price: $13.94 List price: $16.80
  • Ref No: 2138
  • Part No: 151903
  • Qty Req: 3
Our price: $72.38 List price: $87.20
  • Ref No: 2196
  • Part No: 160128
  • Qty Req: 1
Our price: $330.92 List price: $398.70
  • Ref No: 2197
  • Part No: 160532
  • Qty Req: 1
Our price: $332.33 List price: $400.40
  • Ref No: 2244
  • Part No: 160364
  • Qty Req: 2
Our price: $6.97 List price: $8.40
  • Ref No: 2465
  • Part No: 180403
  • Qty Req: 8
Our price: $1.83 List price: $2.20
  • Ref No: 2466
  • Part No: 180406
  • Qty Req: 3
Our price: $1.74 List price: $2.10
  • Ref No: 22
  • Part No: 160344
  • Qty Req: 1
Our price: $3.82 List price: $4.60
  • Ref No: 2582
  • Part No: 180504
  • Qty Req: 3
Our price: $1.99 List price: $2.40
  • Ref No: 2584
  • Part No: 180506
  • Qty Req: 3
Our price: $1.58 List price: $1.90
  • Ref No: 2606
  • Part No: 180529
  • Qty Req: 12
Our price: $2.32 List price: $2.80
  • Ref No: 2616
  • Part No: 180538
  • Qty Req: 24
Our price: $2.32 List price: $2.80
  • Ref No: 4864
  • Part No: 120282
  • Qty Req: 2
Our price: $51.29 List price: $61.80
  • Ref No: 5747
  • Part No: 1604B7
  • Qty Req: 4
Our price: $264.11 List price: $318.20
  • Ref No: 5955
  • Part No: 180423
  • Qty Req: 2
Our price: $1.83 List price: $2.20
  • Ref No: 7600
  • Part No: 140336
  • Qty Req: 3
Our price: $1.74 List price: $2.10
