For your medium-pressure spraying needs, select this Hypro/AR D50 & Honda GX 160 Engine Assembly. With an upper flow rate of 14 GPM and an ideal pressure range of 350 to 400 PSI, the pump is appropriately designed for systems that spray herbicides, pesticides and liquid fertilizers. Additionally, it's paired with a 5.5 HP Honda commercial-grade engine for consistent, reliable power.

Hypro/Pentair is no longer distributing the 9910 series of diaphragm pumps, components, and related parts; however, the pumps and repair parts are still available and will now feature factory labeling.

These 2 diaphragm, medium pressure, epoxy-coated pumps achieve up to 14.8 gpm (56 lpm) and 580 psi (40 bar). Pressure and output are designed for optimum performance of small to medium-sized sprayers. Pentair Hypro medium pressure diaphragm pumps can be adapted for male 1-3/8" splined shaft, female 1-3/8" splined shaft, 1" solid shaft, or gear reduction drive options. Honda's GX series engines are legendary for superior reliability and performance. And there's no doubt about it: the GX160 lives up to the legend. Lower noise levels, lower vibration, and lower emissions without sacrificing power output or performance.

D50 (AR50):

• Max Flow: 14.8 GPM
• Max Pressure: 350 PSI
• Includes 9910-GS40GI pressure regulator and 9910-KIT1640 gearbox with 3/4” hollow shaft for 5–6.5 HP engines
• Port Sizes: 1-1/4” HB inlet, (2) 1/2” HB outlets, 3/4” HB bypass
• Shaft Rotation: CW and CCW
• Diaphragms: 2 semi-hydraulic BlueFlex
• Housing: Anodized aluminum
• Max Fluid Temp: 140°F
• Weight: 45 lbs

Honda GX160 (Recoil Start):

• Type: Air-cooled 4-stroke OHV
• Displacement: 163 cc
• Power: 4.8 HP @ 3600 RPM
• Torque: 7.6 lb-ft @ 2500 RPM
• Shaft: 3/4” solid keyed (CCW rotation)
• Compression Ratio: 9.0:1
• Ignition: Transistorized magneto
• Lubrication: Splash system
• Air Cleaner: Dual element
• Oil Capacity: 0.61 qt
• Fuel Capacity: 3.3 qt (86+ octane)
• Weight: 33 lbs
• Dimensions: 12.2” L x 14.3” W x 13.6” H
