Hypro 9233C-SP Pedestal Mount Transfer Pump

Hypro 9233C-SP Pedestal Mount Transfer Pump

Brand:
Hypro
Weight:
106.0 lb
Item #
9233CSP
Skip to product information
1 of 1

Hypro 9233C-SP Pedestal Mount Transfer Pump

Hypro 9233C-SP Pedestal Mount Transfer Pump

Brand:
Hypro
Weight:
106.0 lb
Item #
9233CSP

Regular price $865.22
Sale price $865.22 Regular price List Price: $1,573.13

We're here to help!

Let us know if you need assistance finding the right spray equipment

Earn 2,596 points with this purchase.

View full details

Collapsible content

Product Overview

Hypro 9233C-SP Cast Iron Pedestal Mount Transfer Pump

330 gpm, 60 psi, 3" x 3" Ports

Hypro’s line of high-powered, self-priming cast iron transfer pumps are available in multiple configurations including PowerPro™ gas engine drive, hydraulic motor drive, pump kit for gas engines, pedestal pump, and pump kit for electric motor.

With flow rates up to 330 gpm and pressures up to 60 psi, these transfer pumps deliver solutions for your fluid and chemical transfer needs.

Parts breakdown

Diagram

Diagram parts

Parts list

  • Discharge Flange (3" NPT)
    • Ref No: 1
    • Part No: 24040361
    • Qty Req: 1
    Our price: $40.00 List price: $49.38
  • Inlet Flange (3" NPT)
    • Ref No: 2
    • Part No: 24040364
    • Qty Req: 1
    Our price: $41.10 List price: $50.74
  • Mounting Flange (NEMA C)
    • Ref No: 3
    • Part No: 07509733C
    • Qty Req: 1
    Our price: $122.99 List price: $151.84
  • Impeller w/Shaft (1-3/8")
    • Ref No: 5
    • Part No: 04009733C
    • Qty Req: 1
    Our price: $403.86 List price: $498.59
  • Wear Plate
    • Ref No: 8
    • Part No: 32100095
    • Qty Req: 1
    Our price: $31.20 List price: $38.52
  • Discharge Flange Gasket (EPDM)
    • Ref No: 9
    • Part No: 17000219
    • Qty Req: 1
    Our price: $13.20 List price: $16.30
  • Flapper Valve Assembly (EPDM)
    • Ref No: 10
    • Part No: 17000220
    • Qty Req: 1
    Our price: $40.00 List price: $49.38
  • Gasket
    • Ref No: 11
    • Part No: 17100018
    • Qty Req: 1
    Our price: $3.12 List price: $3.85
  • Mechanical Seal (Viton)
    • Ref No: 13
    • Part No: 21200047
    • Qty Req: 1
    Our price: $118.07 List price: $145.76
  • Handle
    • Ref No: 14
    • Part No: 28010008a
    • Qty Req: 1
    Our price: $67.03 List price: $82.75
  • Washer (Plastic)
    • Ref No: 15
    • Part No: 17000221
    • Qty Req: 2
    Our price: $0.96 List price: $1.19
  • Shaft Sleeve Clamp Assy. (1")
    • Ref No: 16
    • Part No: 14200033
    • Qty Req: 1
    Our price: $83.30 List price: $102.84
  • Self Priming Chamber
    • Ref No: 18
    • Part No: 01509033C
    • Qty Req: 1
    Our price: $291.31 List price: $359.64
  • Acorn Nut
    • Ref No: 19
    • Part No: 22530011
    • Qty Req: 2
    Our price: $3.56 List price: $4.39
  • Screw
    • Ref No: 20
    • Part No: 22150005
    • Qty Req: 2
    Our price: $3.56 List price: $4.39
  • Stud
    • Ref No: 23
    • Part No: 22050022
    • Qty Req: 6
    Our price: $2.51 List price: $3.10
