Udor RO-160/C Diaphragm Pump (Replaced by ZETA-170/C)

Udor RO-160/C Diaphragm Pump (Replaced by ZETA-170/C)

Brand:
Udor
Weight:
56.0 lb
Item #
RO160C
Skip to product information
1 of 1

Udor RO-160/C Diaphragm Pump (Replaced by ZETA-170/C)

Udor RO-160/C Diaphragm Pump (Replaced by ZETA-170/C)

Brand:
Udor
Weight:
56.0 lb
Item #
RO160C

Regular price $1,555.90
Sale price $1,555.90 Regular price List Price: $2,828.90

Free Shipping on Qualified Orders Over $100

In stock orders placed within

ship out same day. Learn more

Earn 4,668 points with this purchase.

View full details

Collapsible content

Product Overview

Diaphragm pumps are used for many important applications and are often vital components of gasoline engines with one-inch cylinders. This particular model features four diaphragms with a mounting rail, pulsation dampener, and a six spline male PTO shaft measuring 1 3/8-inches. The Udor RO series has glass-filled nylon manifolds and plasticized aluminum heads. Control units are not included with this pump.

Manufacturer description

**Replaced by ZETA-170/C** Four diaphragm pump with pulsation dampener, mounting rails & a 1-3/8", six spline male PTO shaft. UDOR RO Series Pumps Have Plasticized Aluminum Heads And Glass Filled Nylon Manifolds. Control Units Not Included. RO-160 low pressure diaphragm pumps are excellent for various horticultural and agricultural spraying applications. Simplicity of design and common parts allow easy and affordable maintenance. Liquid handling parts are plasticized aluminum, glass-filled nylon and stainless steel. Built-in pulsation dampener is standard on all models. Standard RO-160 comes with a 1-3/8" six splined male PTO shaft. RO-160/CC comes with a dual 1-3/8" six-splined male PTO thru-shaft.

Features

  • Max flow: 42 gpm
  • Max pressure: 300 psi
  • Shaft: 1-3/8" 6-spline male PTO shaft
  • Port sizes: 1-1/2" HB inlet, 1" HB outlet
  • Pump shaft rotation: CW and CCW
  • Diaphragms: 4, semi-hydraulic, Desmopan® standard Buna available
  • Housing: Anodized aluminum
  • Max fluid temperature: 140°F
  • Weight: 56 lbs

Parts breakdown

Diagram

Diagram parts

Parts list

  • Connecting Rod Ring
    • Ref No: 6
    • Part No: 000108
    • Qty Req: 2
    Our price: $59.84 List price: $72.10
  • Crankcase
    • Ref No: 43
    • Part No: 000229
    • Qty Req: 1
    Our price: $603.74 List price: $727.40
  • Crankshaft (RO-160)
    • Ref No: 58
    • Part No: 000246
    • Qty Req: 1
    Our price: $474.76 List price: $572.00
  • Accumulator Base
    • Ref No: 81
    • Part No: 000315
    • Qty Req: 1
    Our price: $148.57 List price: $179.00
  • Seal
    • Ref No: 156
    • Part No: 000702
    • Qty Req: 2
    Our price: $18.27 List price: $22.01
  • Diaphragm Bolt (BETA-150/200/240, OMEGA-140/170, RO-70/160/210/250/320)
    • Ref No: 238
    • Part No: 0010203
    • Qty Req: 4
    Our price: $18.59 List price: $22.40
  • Inlet Hose Barb (KAPPA-30/33/40/43, RO-160)
    • Ref No: 357
    • Part No: 020218
    • Qty Req: 1
    Our price: $15.44 List price: $18.60
  • Hose Barb Elbow (KAPPA-100, RO-160/320)
    • Ref No: 370
    • Part No: 020278
    • Qty Req: 1
    Our price: $24.73 List price: $29.80
  • Sleeve
    • Ref No: 489
    • Part No: 020614
    • Qty Req: 4
    Our price: $173.97 List price: $209.60
  • Oil Cap **Obsolete - no longer available. Must buy 603301 complete assembly**
    • Ref No: 540
    • Part No: 020898
    • Qty Req: 1
    Our price: $16.52 List price: $19.90
  • Accumulator Head
    • Ref No: 557
    • Part No: 020820
    • Qty Req: 1
    Our price: $92.46 List price: $111.40
  • Pump Body (RO-160)
    • Ref No: 618
    • Part No: 020925
    • Qty Req: 1
    Our price: $557.76 List price: $672.00
  • Pump Body (RO-160/CC)
    • Ref No: 619
    • Part No: 020926
    • Qty Req: 1
    Our price: $519.33 List price: $625.70
  • BEARING
    • Ref No: 738
    • Part No: 021607
    • Qty Req: 1
    Our price: $219.12 List price: $264.00
  • Air Valve Cap (KAPPA-100/120, RO-70/110/160)
    • Ref No: 747
    • Part No: 021801
    • Qty Req: 1
    Our price: $3.07 List price: $3.70
  • Washer (RO-160/210/250)
    • Ref No: 802
    • Part No: 0030128
    • Qty Req: 2
    Our price: $107.07 List price: $129.00
  • Spacer Ring
    • Ref No: 838
    • Part No: 030259
    • Qty Req: 2
    Our price: $11.87 List price: $14.30
  • Nut
    • Ref No: 845
    • Part No: 030301
    • Qty Req: 6
    Our price: $1.91 List price: $2.30
  • Bearing Flange (RO-160/210/250)
    • Ref No: 919
    • Part No: 050167
    • Qty Req: 1
    Our price: $144.92 List price: $174.60
  • Barb Nut
    • Ref No: 1045
    • Part No: 060432
    • Qty Req: 1
    Our price: $16.68 List price: $20.10
  • Suction Nut
    • Ref No: 1055
    • Part No: 060450
    • Qty Req: 1
    Our price: $18.09 List price: $21.80
  • Aluminum Gasket
    • Ref No: 1072
    • Part No: 060509
    • Qty Req: 1
    Our price: $1.74 List price: $2.10
  • Air Valve Assembly
    • Ref No: 11
    • Part No: 060816
    • Qty Req: 1
    Our price: $20.50 List price: $24.70
  • Diaphragm Buna-N (Opt.)
    • Ref No: 1291
    • Part No: 090302
    • Qty Req: 4
    Our price: $31.46 List price: $37.90
  • Accumulator Diaphragm
    • Ref No: 1300
    • Part No: 090314
    • Qty Req: 1
    Our price: $27.89 List price: $33.60
  • O-Ring
    • Ref No: 1365
    • Part No: 110101
    • Qty Req: 8
    Our price: $4.15 List price: $5.00
  • O-Ring
    • Ref No: 1366
    • Part No: 110102
    • Qty Req: 1
    Our price: $2.66 List price: $3.20
  • O-Ring
    • Ref No: 1376
    • Part No: 110116
    • Qty Req: 1
    Our price: $2.57 List price: $3.10
  • O-Ring
    • Ref No: 1382
    • Part No: 110129
    • Qty Req: 1
    Our price: $2.49 List price: $3.00
  • O-Ring
    • Ref No: 1398
    • Part No: 110142
    • Qty Req: 1
    Our price: $2.82 List price: $3.40
  • O-Ring
    • Ref No: 1401
    • Part No: 110158
    • Qty Req: 1
    Our price: $9.30 List price: $11.20
  • O-Ring
    • Ref No: 1434
    • Part No: 1101D1
    • Qty Req: 1
    Our price: $5.81 List price: $7.00
  • Mounting Rail
    • Ref No: 1457
    • Part No: 120229
    • Qty Req: 2
    Our price: $55.44 List price: $66.80
  • Piston
    • Ref No: 1569
    • Part No: 120506
    • Qty Req: 4
    Our price: $104.75 List price: $126.20
  • Valve Assembly
    • Ref No: 1709
    • Part No: 600608
    • Qty Req: 8
    Our price: $42.08 List price: $50.70
  • Oil Reservoir Assembly
    • Ref No: 1740
    • Part No: 603301
    • Qty Req: 1
    Our price: $68.23 List price: $82.20
  • Piston/Rod Assembly
    • Ref No: 1776
    • Part No: 601530
    • Qty Req: 4
    Our price: $216.63 List price: $261.00
  • 6031.09 Pulsation Dampener
    • Ref No: 1811
    • Part No: 603109
    • Qty Req: 1
    Our price: $258.30 List price: $311.20
  • Washer
    • Ref No: 1843
    • Part No: 140307
    • Qty Req: 2
    Our price: $1.33 List price: $1.60
  • Washer
    • Ref No: 18
    • Part No: 140309
    • Qty Req: 18
    Our price: $1.33 List price: $1.60
  • Washer
    • Ref No: 1845
    • Part No: 140310
    • Qty Req: 22
    Our price: $0.94 List price: $1.13
  • Connecting Rod Pin
    • Ref No: 1962
    • Part No: 150201
    • Qty Req: 4
    Our price: $22.00 List price: $26.50
  • Snap Ring
    • Ref No: 2046
    • Part No: 150602
    • Qty Req: 8
    Our price: $1.91 List price: $2.30
  • Snap Ring
    • Ref No: 2052
    • Part No: 150616
    • Qty Req: 1
    Our price: $4.90 List price: $5.90
  • Connecting Rod
    • Ref No: 2153
    • Part No: 151920
    • Qty Req: 4
    Our price: $75.28 List price: $90.70
  • Manifold
    • Ref No: 2184
    • Part No: 160112
    • Qty Req: 5
    Our price: $53.62 List price: $64.60
  • Suction Manifold
    • Ref No: 2224
    • Part No: 160220
    • Qty Req: 1
    Our price: $57.85 List price: $69.70
  • Discharge Manifold
    • Ref No: 2225
    • Part No: 160221A
    • Qty Req: 1
    Our price: $56.11 List price: $67.60
  • Oil Plug
    • Ref No: 2251
    • Part No: 160302
    • Qty Req: 1
    Our price: $8.47 List price: $10.20
  • Plug
    • Ref No: 2282
    • Part No: 160350
    • Qty Req: 1
    Our price: $8.55 List price: $10.30
  • Head
    • Ref No: 2318
    • Part No: 160436
    • Qty Req: 4
    Our price: $171.64 List price: $206.80
  • Discharge Manifold
    • Ref No: 2356
    • Part No: 160515
    • Qty Req: 1
    Our price: $57.85 List price: $69.70
  • Bolt
    • Ref No: 2465
    • Part No: 180403
    • Qty Req: 6
    Our price: $2.32 List price: $2.80
  • Bolt
    • Ref No: 2466
    • Part No: 180406
    • Qty Req: 3
    Our price: $2.24 List price: $2.70
  • Bolt
    • Ref No: 2589
    • Part No: 180531
    • Qty Req: 2
    Our price: $1.91 List price: $2.30
  • Washer
    • Ref No: 7600
    • Part No: 140336
    • Qty Req: 3
    Our price: $2.24 List price: $2.70
  • PTO Safety Shield (Optional)
    • Ref No: 7650
    • Part No: 121902
    • Qty Req: 1
    Our price: $41.83 List price: $50.40
  • Diaphragm Desmopan (Std.)
    • Ref No: 8113
    • Part No: 090334
    • Qty Req: 4
    Our price: $52.21 List price: $62.90
