Hypro D1064 Pump

Hypro D1064 Pump

Item Code:
9910D1064
Weight:
58.0 lb
Manufacturer:
Hypro
Our price:
$1,145.00
List price:
$2,279.00
Overview:
Because of their high pressure threshold of 725 PSI, the D1064 Hypro pump makes spraying industrial fluids incredibly easy. It's built to withstand corrosive materials like pesticides, liquid fertilizers and many more. Pump is equipped with single male PTO shaft with a flange opposite if you need to run something off both ends.

Hypro/Pentair is no longer distributing the 9910 series of diaphragm pumps, components, and related parts. Products with Hypro labeling will be unavailable soon. If you order one of these products you may receive the original factory version manufactured by AR in Italy. Specs and performance are the same.

Manufacturer Description:

Hypro high pressure diaphragm pumps are recommended for spraying of herbicides, pesticides, liquid fertilizers and many other hard to handle fluids. Low-cost maintenance and almost wear-free operation make these pumps ideal for a wide variety of spraying jobs. Pressure and output are designed for optimum performance of medium to large-sized sprayers. Hypro high pressure diaphragm pumps are supplied with single or double-splined through-shafts. Pumps include pulsation dampeners.

Features:

  • Max flow: 28.7 gpm
  • Max pressure: 725 psi
  • Shaft: Flanged adapter and 1-3/8" 6 spline male PTO shaft
  • Port sizes: 1-1/2" HB inlet, 3/4" NPT outlet
  • Pump shaft rotation: CW and CCW
  • Diaphragms: 4, semi-hydraulic, Desmopan® standard Buna available
  • Housing: Anodized aluminum
  • Mounting base: Included
  • Recommended control unit: 9910-VDR50 (direct mount) or 9910-GS50GI (remote mount)
  • Recommended gearbox: 9910-KIT1642 with 1" hollow shaft for mounting on 13 hp engines
  • Max fluid temperature: 140°F
  • Weight: 54 lbs

Parts breakdown

 Parts breakdown parts

Parts list

  • Ref No: 1
  • Part No: 9910580360
  • Qty Req: 4
Our price: $13.20 List price: $16.30
  • Ref No: 2
  • Part No: 99101040180
  • Qty Req: 4
Our price: $18.78 List price: $23.18
  • Ref No: 4
  • Part No: 99101500080
  • Qty Req: 4
Our price: $87.11 List price: $107.54
  • Ref No: 5
  • Part No: 9910650190
  • Qty Req: 4
Our price: $18.08 List price: $22.32
  • Ref No: 6
  • Part No: 99101040120
  • Qty Req: 4
Our price: $124.91 List price: $154.21
  • Ref No: 7
  • Part No: 99101040070
  • Qty Req: 4
Our price: $33.99 List price: $41.96
  • Ref No: 8
  • Part No: 99101040270
  • Qty Req: 8
Our price: $5.32 List price: $6.57
  • Ref No: 10
  • Part No: 99101400150
  • Qty Req: 1
Our price: $28.27 List price: $34.90
  • Ref No: 11
  • Part No: 9910650200
  • Qty Req: 1
Our price: $271.70 List price: $335.43
  • Ref No: 12
  • Part No: 99101800200
  • Qty Req: 1
Our price: $580.77 List price: $717.00
  • Ref No: 13
  • Part No: 9910161050
  • Qty Req: 1
Our price: $15.30 List price: $18.89
  • Ref No: 14
  • Part No: 99101800170
  • Qty Req: 2
Our price: $73.06 List price: $90.20
  • Ref No: 15
  • Part No: 99101040551
  • Qty Req: 2
Our price: $223.38 List price: $275.78
  • Ref No: 16
  • Part No: 9910680350
  • Qty Req: 2
Our price: $2.48 List price: $3.06
  • Ref No: 17
  • Part No: 9910380241
  • Qty Req: 2
Our price: $1.51 List price: $1.86
  • Ref No: 18
  • Part No: 9910390180
  • Qty Req: 2
Our price: $1.51 List price: $1.86
  • Ref No: 19
  • Part No: 99101040552
  • Qty Req: 2
Our price: $199.45 List price: $246.23
  • Ref No: 20
  • Part No: 99101480040
  • Qty Req: 8
Our price: $7.88 List price: $9.73
  • Ref No: 21
  • Part No: 9910750060
  • Qty Req: 8
Our price: $8.59 List price: $10.61
  • Ref No: 22
  • Part No: 99101040470
  • Qty Req: 3
Our price: $4.66 List price: $5.75
  • Ref No: 23
  • Part No: 9910320360
  • Qty Req: 2
Our price: $1.72 List price: $2.12
  • Ref No: 25
  • Part No: 9910540360
  • Qty Req: 1
Our price: $2.60 List price: $3.21
  • Ref No: 26
  • Part No: 99101800280
  • Qty Req: 1
Our price: $118.04 List price: $145.73
  • Ref No: 27
  • Part No: 99101800300
  • Qty Req: 1
Our price: $20.96 List price: $25.88
  • Ref No: 28
  • Part No: 99101800270
  • Qty Req: 1
Our price: $55.62 List price: $68.67
  • Ref No: 29
  • Part No: 9910650542
  • Qty Req: 1
Our price: $1.97 List price: $2.43
  • Ref No: 30
  • Part No: 99101800350
  • Qty Req: 1
Our price: $15.30 List price: $18.89
  • Ref No: 31
  • Part No: 9910640070
  • Qty Req: 1
Our price: $1.51 List price: $1.86
  • Ref No: 32
  • Part No: 99101040340
  • Qty Req: 2
Our price: $41.93 List price: $51.76
  • Ref No: 33
  • Part No: 9910250310
  • Qty Req: 2
Our price: $1.93 List price: $2.38
  • Ref No: 34
  • Part No: 9910540530
  • Qty Req: 1
Our price: $25.60 List price: $31.60
  • Ref No: 35
  • Part No: 9910770571
  • Qty Req: 8
Our price: $1.89 List price: $2.33
  • Ref No: 36
  • Part No: 9910540540
  • Qty Req: 1
Our price: $18.08 List price: $22.32
  • Ref No: 37
  • Part No: 9910540550
  • Qty Req: 1
Our price: $29.71 List price: $36.68
  • Ref No: 38
  • Part No: 99101800290
  • Qty Req: 1
Our price: $79.17 List price: $97.74
  • Ref No: 39
  • Part No: 99101820080
  • Qty Req: 1
Our price: $77.13 List price: $95.22
  • Ref No: 40
  • Part No: 99101040570
  • Qty Req: 1
Our price: $14.47 List price: $17.86
  • Ref No: 41
  • Part No: 99101040050
  • Qty Req: 1
Our price: $49.69 List price: $61.34
  • Ref No: 42
  • Part No: 99101800161
  • Qty Req: 1
Our price: $13.62 List price: $16.82
  • Ref No: 43
  • Part No: 99101040060
  • Qty Req: 3
Our price: $8.74 List price: $10.79
  • Ref No: 44
  • Part No: 99101800150
  • Qty Req: 1
Our price: $165.03 List price: $203.74
  • Ref No: 45
  • Part No: 99101040370
  • Qty Req: 12
Our price: $4.02 List price: $4.96
  • Ref No: 46
  • Part No: 9910780060
  • Qty Req: 6
Our price: $1.72 List price: $2.12
  • Ref No: 48
  • Part No: 99101040690
  • Qty Req: 1
Our price: $24.41 List price: $30.14
  • Ref No: 49
  • Part No: 99101820040
  • Qty Req: 1
Our price: $494.94 List price: $611.04
  • Ref No: 50
  • Part No: 9910750040
  • Qty Req: 1
Our price: $1.60 List price: $1.97
  • Ref No: 51
  • Part No: 99101800060
  • Qty Req: 1
Our price: $15.93 List price: $19.67
  • Ref No: 52
  • Part No: 9910620030
  • Qty Req: 8
Our price: $1.97 List price: $2.43
  • Ref No: 53
  • Part No: 9910750030
  • Qty Req: 1
Our price: $47.82 List price: $59.04
  • Ref No: 55
  • Part No: 99101820070
  • Qty Req: 1
Our price: $86.62 List price: $106.94
  • Ref No: 56
  • Part No: 99101400140
  • Qty Req: 1
Our price: $18.23 List price: $22.51
  • Ref No: 57
  • Part No: 99101500350
  • Qty Req: 2
Our price: $52.50 List price: $64.82
  • Ref No: 59
  • Part No: 99101300190
  • Qty Req: 4
Our price: $46.27 List price: $57.12
