Hypro 9306S-HM1C-3U Centrifugal Pump

Hypro 9306S-HM1C-3U Centrifugal Pump

Brand:
Hypro
Weight:
35.0 lb
Item #
9306SHM1C3U
Skip to product information
1 of 1

Hypro 9306S-HM1C-3U Centrifugal Pump

Hypro 9306S-HM1C-3U Centrifugal Pump

Brand:
Hypro
Weight:
35.0 lb
Item #
9306SHM1C3U

Regular price $2,230.87
Sale price $2,230.87 Regular price List Price: $4,056.13

Free Shipping on Qualified Orders Over $100

In stock orders placed within

ship out same day. Learn more

Earn 6,693 points with this purchase.

View full details

Collapsible content

Product Overview

Hypro 9306S-HM1C-3U Centrifugal Pump

Manufacturer description

Hypro centrifugal pumps are designed for creating and boosting pressure in fluid circuits. The pump operates by taking in fluid from the inlet port after which it is slung by the impeller and expelled through the outlet port. Construction features include housings, impellers and seals which come in a variety of materials in order to be resistant to a range of chemicals. Standard models of centrifugal pumps rotate clockwise, when looking at the shaft end of the pump.

Features

  • Hydraulic motor drive (for open center, closed center, and load-sensing systems)
  • Port sizes: 300 X 220 universal flange
  • Max flow: 283 gpm
  • Max pressure: 127 psi
  • Housing: Stainless Steel
  • Impeller: Polypropylene (GTX available)
  • Pump seals: Stainless Steel models Life Guard silicon carbide
  • Motor: internal gear gerotor
  • Motor capacities: 9-24 gpm
  • HM1C: 9-14 gpm
  • HM3C: 17-24 gpm
  • HM5C: 13-18 gpm
  • Max. motor psi: 3000 continuous duty
  • Hydraulic ports: 1/2" NPT inlet, 3/4" NPT outlet
  • Hydraulic motor seal: double-lip PTFE and case drain available

Parts breakdown

Diagram

Diagram parts
