Name: John Blue DP-43 Diaphragm Pump (Replaced by DP-43-FP)
Brand: John Blue
SKU: DP43
Price: 655.07 USD
Availability: InStock

John Blue DP-43 Diaphragm Pump (Replaced by DP-43-FP)

Brand:

John Blue

Weight:

13.0 lb

Item #

DP43

1 1

John Blue DP-43 Diaphragm Pump (Replaced by DP-43-FP)

Brand:

John Blue

Weight:

13.0 lb

Item #

DP43

$655.07

$655.07 List Price: ~~$1,310.15~~

Free Shipping on Qualified Orders Over $100

Orders of in-stock products placed within

ship out same day. Learn more

Product variants

Earn 1,965 points with this purchase.

See Details

View full details

Product Overview

John Blue DP-43 Diaphragm Pump (Replaced by DP-43-FP)

4.3 GPM, 290 PSI

3/4" Inlet, 1/2" Outlet, 650 Max RPM.

Resources

Download Product Manual

Features

semi-hydraulic diaphragm pump.
ideal for gardening, small sprayers, washers and liquid transfer.
Compact and lightweight.
Can be driven by PTO, electric motor or gasoline engine.
Wetted parts are plastic coated to withstand today's agricultural chemicals.
Diaphragms are constructed from chemical resistant elastomers for excellent corrosion resistance.

Parts breakdown

Diagram

Parts list

Crankcase
- Ref No: 1
- Part No: DP94000109
- Qty Req: 1
Our price: $188.31 List price: $251.09
Connecting Rod Ring
- Ref No: 2
- Part No: DP94004776
- Qty Req: 2
Our price: $25.91 List price: $34.54
Connecting Rod
- Ref No: 3
- Part No: DP94000809
- Qty Req: 2
Our price: $48.21 List price: $64.28
Piston
- Ref No: 4
- Part No: DP94001708
- Qty Req: 2
Our price: $92.95 List price: $123.93
Piston Pin
- Ref No: 5
- Part No: DP85200400
- Qty Req: 2
Our price: $16.48 List price: $21.97
Snap Ring
- Ref No: 6
- Part No: DP80000300
- Qty Req: 4
Our price: $3.28 List price: $4.37
Piston Sleeve
- Ref No: 7
- Part No: DP94000701
- Qty Req: 2
Our price: $93.19 List price: $124.27
Piston Diaphragm
- Ref No: 8
- Part No: DP94004031
- Qty Req: 2
Our price: $21.91 List price: $29.21
Piston Diaphragm, Viton
- Ref No: 8
- Part No: DP94004033
- Qty Req: 2
Our price: $268.74 List price: $358.33
Washer
- Ref No: 9
- Part No: DP94003632
- Qty Req: 2
Our price: $26.92 List price: $35.89
Bolt
- Ref No: 10
- Part No: DP94004843
- Qty Req: 2
Our price: $18.10 List price: $24.13
Pump Head
- Ref No: 11
- Part No: DP94000209
- Qty Req: 2
Our price: $167.51 List price: $223.34
Screw
- Ref No: 12
- Part No: DP86279600
- Qty Req: 12
Our price: $2.92 List price: $3.90
O-Ring
- Ref No: 13
- Part No: DP80318100
- Qty Req: 4
Our price: $2.95 List price: $3.93
Inlet Manifold
- Ref No: 14
- Part No: DP94001432
- Qty Req: 1
Our price: $34.74 List price: $46.32
O-Ring
- Ref No: 15
- Part No: SC80306000
- Qty Req: 1
Our price: $2.84 List price: $3.80
Hose Barb
- Ref No: 16
- Part No: SC84052100
- Qty Req: 1
Our price: $21.09 List price: $28.11
Barb Nut
- Ref No: 17
- Part No: SC82004210
- Qty Req: 1
Our price: $11.97 List price: $15.95
Cap
- Ref No: 18
- Part No: DP94007566
- Qty Req: 1
Our price: $2.07 List price: $2.75
Accumulator Manifold
- Ref No: 19
- Part No: DP94000409
- Qty Req: 1
Our price: $151.10 List price: $201.45
Dampener Diaphragm
- Ref No: 20
- Part No: DP94004131
- Qty Req: 1
Our price: $23.61 List price: $31.47
Top Cover
- Ref No: 21
- Part No: DP94000309
- Qty Req: 1
Our price: $102.21 List price: $136.29
Clamp
- Ref No: 22
- Part No: DP81753700
- Qty Req: 1
Our price: $8.97 List price: $11.96
Nut
- Ref No: 23
- Part No: SC81457500
- Qty Req: 4
Our price: $7.44 List price: $9.91
Air Valve
- Ref No: 25
- Part No: DP86160500
- Qty Req: 1
Our price: $23.76 List price: $31.68
Oil Filler
- Ref No: 27
- Part No: DP94004332
- Qty Req: 1
Our price: $11.78 List price: $15.70
Oil Filler Cap
- Ref No: 28
- Part No: DP94004431
- Qty Req: 1
Our price: $12.32 List price: $16.42
Washer
- Ref No: 31
- Part No: DP84368500
- Qty Req: 8
Our price: $2.79 List price: $3.73
O-Ring
- Ref No: 41
- Part No: DP80321900
- Qty Req: 4
Our price: $2.82 List price: $3.76
O-Ring
- Ref No: 49
- Part No: DP82415400
- Qty Req: 4
Our price: $2.60 List price: $3.45
Check Valve
- Ref No: 51
- Part No: DP94982897
- Qty Req: 4
Our price: $21.10 List price: $28.13
Crankcase Cover Gasket
- Ref No: 54
- Part No: DP94008072
- Qty Req: 1
Our price: $10.30 List price: $13.73
Needle Bearing
- Ref No: 56
- Part No: DP81253100
- Qty Req: 1
Our price: $34.51 List price: $46.01
Spacer
- Ref No: 57
- Part No: DP94002632
- Qty Req: 1
Our price: $9.78 List price: $13.05
Needle Bearing
- Ref No: 58
- Part No: DP81268800
- Qty Req: 1
Our price: $55.62 List price: $74.15
Spacer
- Ref No: 59
- Part No: DP94002732
- Qty Req: 1
Our price: $5.45 List price: $7.26
Snap Ring
- Ref No: 60
- Part No: DP80126400
- Qty Req: 1
Our price: $2.71 List price: $3.61
Mounting Bracket
- Ref No: 61
- Part No: DP94002261
- Qty Req: 1
Our price: $49.25 List price: $65.67
Screw
- Ref No: 64
- Part No: DP86205900
- Qty Req: 4
Our price: $2.46 List price: $3.28
Screw
- Ref No: 63
- Part No: DP86216800
- Qty Req: 4
Our price: $2.75 List price: $3.67
Bearing Housing
- Ref No: 65
- Part No: DP94021609
- Qty Req: 1
Our price: $81.08 List price: $108.11
Oil Seal
- Ref No: 66
- Part No: DP80217810
- Qty Req: 1
Our price: $38.40 List price: $51.21
Ball Bearing
- Ref No: 67
- Part No: DP81283700
- Qty Req: 1
Our price: $101.31 List price: $135.08
