Udor RO-110/C Diaphragm Pump (Replaced by ZETA-120/C)

Udor RO-110/C Diaphragm Pump (Replaced by ZETA-120/C)

Item Code:
RO110C
Weight:
45.0 lb
Manufacturer:
Udor
Our price:
$929.06
List price:
$1,637.70
Overview:

If you're looking for a medium-duty, low-pressure diaphragm pump, then you've found a winner. The Udor RO-110/C was engineered and designed with easy and affordable maintenance in mind. Its three cylinders, glass-filled nylon manifolds and anodized aluminum body make it a solid choice for those in the horticultural and agricultural industries.

Manufacturer Description:

**Replaced by ZETA-120/C** RO-110/C low pressure, 3-cylinder diaphragm pumps are excellent for various horticultural and agricultural spraying applications. Simplicity of design and common parts allow easy and affordable maintenance. A built-in pulsation dampener and 1-3/8" male six-spline PTO shaft are standard. Control unit is not included. PTO safety shield part # 1219.25 is recommended. The RO-110/C has an anodized aluminum body, plasticized aluminum heads, glass-filled nylon manifolds and stainless steel liquid handling parts.

Features:

  • Max flow: 29 gpm
  • Max pressure: 300 psi Ê
  • Max rpm: 540
  • Port sizes: 1-1/2" HB inlet, 3/4" HB outlet
  • Shaft: 1-3/8" male 6 spline PTO
  • Pump shaft rotation: CW and CCW
  • Diaphragms: 3, semi-hydraulic, Desmopan® standard Buna available
  • Housing: Anodized aluminum
  • Recommended pressure regulator: 6047.06/LP
  • Max fluid temperature: 140°F
  • Weight: 45 lbs
