Udor RO-110/C Diaphragm Pump (Replaced by ZETA-120/C)

Udor RO-110/C Diaphragm Pump (Replaced by ZETA-120/C)

Brand:
Udor
Weight:
45.0 lb
Item #
RO110C

Regular price $983.68
Sale price $983.68 Regular price List Price: $1,788.50

Free Shipping on Qualified Orders Over $100

In stock orders placed within

ship out same day. Learn more

Earn 2,951 points with this purchase.

View full details

Collapsible content

Product Overview

If you're looking for a medium-duty, low-pressure diaphragm pump, then you've found a winner. The Udor RO-110/C was engineered and designed with easy and affordable maintenance in mind. Its three cylinders, glass-filled nylon manifolds and anodized aluminum body make it a solid choice for those in the horticultural and agricultural industries.

Manufacturer description

**Replaced by ZETA-120/C** RO-110/C low pressure, 3-cylinder diaphragm pumps are excellent for various horticultural and agricultural spraying applications. Simplicity of design and common parts allow easy and affordable maintenance. A built-in pulsation dampener and 1-3/8" male six-spline PTO shaft are standard. Control unit is not included. PTO safety shield part # 1219.25 is recommended. The RO-110/C has an anodized aluminum body, plasticized aluminum heads, glass-filled nylon manifolds and stainless steel liquid handling parts.

Features

  • Max flow: 29 gpm
  • Max pressure: 300 psi
  • Max rpm: 540
  • Port sizes: 1-1/2" HB inlet, 3/4" HB outlet
  • Shaft: 1-3/8" male 6 spline PTO
  • Pump shaft rotation: CW and CCW
  • Diaphragms: 3, semi-hydraulic, Desmopan® standard Buna available
  • Housing: Anodized aluminum
  • Recommended pressure regulator: 6047.06/LP
  • Max fluid temperature: 140°F
  • Weight: 45 lbs
