Pumptec 360U-190/M960 12V Pump & Motor

Pumptec 360U-190/M960 12V Pump & Motor

Brand:
Pumptec
Weight:
48.0 lb
Item #
81511

Regular price $894.46
Sale price $894.46 Regular price List Price: $1,052.31

Earn 2,683 points with this purchase.

View full details

Collapsible content

Product Overview

Pumptec 360U-190/M960 12V Pump & Motor
QR codes on the new Pumptec manifolds will take you directly to their website service manuals.

Manufacturer description

Pumptec pump series 360U with plunger type design is the most efficient way possible to pressurize water. This efficiency produces up to 20% more pressure or flow for a given power input compared to competitive pumps. The series offers a variety of pump and motor combinations customized to meet specific application requirements. Typical applications include pressure cleaning,Pest spraying and misting. All pumps are factory lubricated for long-lifePerformance. The only tool to completely disassemble the pump to its basic components is a 3/16" hex wrench. Durability andPerformance results from exclusive use of premium materials. All metallic wetted parts are stainless steel. An aircraft-grade anodized aluminum pump with Teflon hard-coat body is nearly indestructible compared to pumps made of castings. The body offers chemical compatibility with a wide variety of chemicals. Epoxy and other coatings are available for high and low pH applications. Flow and pressure can be optimized to exactly match power input to nozzle size, and offers an assortment of eccentrics for low, medium and high pressure to match your application requirement.

  • Performance Features
  • Long Life
  • High-Pressure
  • High-Efficiency
  • Serviceability
  • Durability
  • Application Flexibility
  • Chemical Compatibility
  • Compact Design
  • Enhanced Priming

Features

  • Voltage: 12 VDC
  • Max flow: 2.75 gpm
  • Max pressure: 300 psi
  • Port sizes: (2) 3/8" FNPT inlet, (2) 3/8" FNPT outlet
  • Housing: Anodized aluminum
  • Seals: U-Cup
  • Valves: Stainless steel
  • O-rings: Buna
  • Max draw: 55.0
  • Max fluid temperature: 140°F
  • Weight: 48 lbs

Parts breakdown

Diagram

Diagram parts

Parts list
