John Bean Redline Model 428T Air Sprayer w/ Diaphragm Pump (Tracking Hitch)
400 Gallon Capacity, Tracking Hitch
24 GPM, 650 PSI
Dimensions: 182" L x 64" W x 64" H
Catalog Number 5284559
- 400 gallon round 304 stainless steel with mechanical agitator. One-eighth-turn hinged lid with air vents. Plastic basket-type filler strainer. Tank level sight gauge.
- 32" (.82M) twelve blade variable pitch fan with inside air handling at discharge. Galvanized fan shroud. Stainless steel manifolds. Two speed with neutral gearbox, variable 30 - 60 tractor horsepower.
- PTO Power - Constant velocity
- Remote manual left and right spray control valve plus remote bypass valve. (Electric optional)
- Bertolini PA 908, 3 piston diaphragm, 24 GPM (91L) @ 540 RPM pressure to 650 PSI (45 bar)
- 14 double rollover nozzles with diaphragm check valves
- Suction Strainer mounted under hood on right side, cylindric
