Hypro/Pentair is no longer distributing the 9910 series of diaphragm pumps, components, and related parts; however, the pumps and repair parts are still available and will now feature factory labeling.

**When you order this pump, you will receive the most current version, AR160BP-CC. **

9910-D160 (AR160BP-CC)

Hypro low pressure diaphragm pumps are recommended for ground and low-level spraying of herbicides, pesticides, liquid fertilizers and many other hard-to-handle fluids.

Low-cost maintenance and almost wear-free operation make these pumps ideal for a wide variety of spraying jobs. Pressure and output are designed for optimum performance of medium to large sized sprayers. Hypro low pressure diaphragm pumps can be adapted for splined shaft, hollow shaft, and solid shaft drive options. Pumps include a pulsation dampener.

Download Product Manual

• Max flow: 43.9 gpm
• Max pressure: 290 psi
• Shaft: 1-3/8" 6-spline male PTO thru shaft
• Port Sizes: 2" HB inlet; 1-½" HB outlet
• Pump shaft rotation: CW and CCW
• Diaphragms: 4, semi-hydraulic, BlueFlex® material
• Housing: Anodized aluminum
• Recommended control unit: EMC-3 (3300-0087) and UCM-3 (3300-0088)
• Max fluid temperature: 140° F
• Weight: 67 lbs
