Product Overview

The internally manifolded Comet APS71 is a three diaphragm, high-pressure pump that includes anodized aluminum heads, mounting rails, and dual 1-3/8" six spline male PTO shafts. The pump is ideal for applications such as agricultural spraying, pest and weed control, hydrostatic testing, and general lawn care. This unit handles a wide variety of chemicals, such as de-icing materials, liquid fertilizers, and herbicides.

Manufacturer description

Three diaphragm pump with 1-3/8" Male PTO shaft on both ends. High pressure internal manifold pumps with anodized aluminum heads for less leak points. Great for lawn care, pest control, hydrostatic testing and agricultural spraying.

Features

  • Max flow: 18 gpm
  • Max pressure: 725 psi
  • Max rpm: 550
  • Port sizes: 1-1/4" HB inlet, 1/2" HB outlet
  • Shaft: Dual 1-3/8" male 6-spline PTO
  • Pump shaft rotation: CW and CCW
  • Diaphragms: 3, semi-hydraulic, Buna standard Desmopan® and Viton® available
  • Housing: Anodized aluminum
  • Recommended pressure regulator: 1204/677 or 1204/680
  • Max fluid temperature: 140°F
  • Weight: 45 lbs

Parts breakdown

Diagram

Diagram parts

Parts list

  • Wing Nut
    • Ref No: 1
    • Part No: 12000011
    • Qty Req: 1
    Our price: $15.22 List price: $17.91
  • Suction Elbow
    • Ref No: 2
    • Part No: 28010009
    • Qty Req: 1
    Our price: $26.81 List price: $31.54
  • O-Ring
    • Ref No: 3
    • Part No: 12100034
    • Qty Req: 1
    Our price: $1.13 List price: $1.33
  • Coupling
    • Ref No: 4
    • Part No: 28030108
    • Qty Req: 1
    Our price: $36.24 List price: $42.64
  • O-Ring
    • Ref No: 5
    • Part No: 12100173
    • Qty Req: 1
    Our price: $1.27 List price: $1.49
  • Wing Nut
    • Ref No: 7
    • Part No: 12000038
    • Qty Req: 1
    Our price: $8.11 List price: $9.54
  • Hose Barb
    • Ref No: 8
    • Part No: 28020018
    • Qty Req: 1
    Our price: $7.61 List price: $8.95
  • Gasket
    • Ref No: 9
    • Part No: 12090013
    • Qty Req: 1
    Our price: $0.90 List price: $1.06
  • Left Tap
    • Ref No: 10
    • Part No: 28260030
    • Qty Req: 1
    Our price: $69.50 List price: $81.76
  • Complete Tap
    • Ref No: 11
    • Part No: 12140014
    • Qty Req: 1
    Our price: $89.08 List price: $104.80
  • Screw
    • Ref No: 13
    • Part No: 36090006
    • Qty Req: 6
    Our price: $1.79 List price: $2.10
  • Manifold Flange
    • Ref No: 14
    • Part No: 10090095
    • Qty Req: 1
    Our price: $199.88 List price: $266.50
  • O-Ring
    • Ref No: 15
    • Part No: 12100349
    • Qty Req: 1
    Our price: $4.52 List price: $5.32
  • O-Ring
    • Ref No: 16
    • Part No: 12100345
    • Qty Req: 1
    Our price: $4.80 List price: $5.65
  • O-Ring
    • Ref No: 17
    • Part No: 12100347
    • Qty Req: 1
    Our price: $1.84 List price: $2.17
  • Oil Seal
    • Ref No: 18
    • Part No: 00190083
    • Qty Req: 1
    Our price: $13.90 List price: $16.35
  • Screw
    • Ref No: 20
    • Part No: 36090078
    • Qty Req: 12
    Our price: $4.23 List price: $4.98
  • Washer
    • Ref No: 21
    • Part No: 28110098
    • Qty Req: 11
    Our price: $0.48 List price: $0.57
  • Pump Manifold
    • Ref No: 22
    • Part No: 32180103
    • Qty Req: 3
    Our price: $130.94 List price: $154.05
  • O-Ring
    • Ref No: 23
    • Part No: 12100047
    • Qty Req: 6
    Our price: $1.03 List price: $1.21
  • O-Ring
    • Ref No: 24
    • Part No: 12100443
    • Qty Req: 6
    Our price: $1.26 List price: $1.48
  • Valve Seat
    • Ref No: 25
    • Part No: 30090115
    • Qty Req: 6
    Our price: $18.65 List price: $21.94
  • Valve Plate
    • Ref No: 26
    • Part No: 36040023
    • Qty Req: 6
    Our price: $3.21 List price: $3.78
  • Valve Spring
    • Ref No: 27
    • Part No: 18020015
    • Qty Req: 6
    Our price: $1.82 List price: $2.14
  • Valve Cage
    • Ref No: 28
    • Part No: 12050029
    • Qty Req: 6
    Our price: $2.20 List price: $2.59
  • Valve Assembly
    • Ref No: 29
    • Part No: 12200035
    • Qty Req: 6
    Our price: $27.27 List price: $32.08
  • O-Ring
    • Ref No: 30
    • Part No: 12100032
    • Qty Req: 6
    Our price: $1.24 List price: $1.46
  • Plug
    • Ref No: 31
    • Part No: 32020197
    • Qty Req: 3
    Our price: $42.62 List price: $50.14
  • Screw
    • Ref No: 33
    • Part No: 36090049
    • Qty Req: 2
    Our price: $10.43 List price: $12.27
  • Pump Mounting Bracket
    • Ref No: 34
    • Part No: 24000066
    • Qty Req: 2
    Our price: $35.78 List price: $42.09
  • O-Ring
    • Ref No: 35
    • Part No: 12100044
    • Qty Req: 1
    Our price: $2.36 List price: $2.48
  • Plug
    • Ref No: 36
    • Part No: 32000010
    • Qty Req: 1
    Our price: $20.74 List price: $24.40
  • Connecting Rod Assembly (Set of 3)
    • Ref No: 37
    • Part No: 02050053
    • Qty Req: 1
    Our price: $170.50 List price: $200.59
  • Piston
    • Ref No: 38
    • Part No: 24090067
    • Qty Req: 3
    Our price: $87.93 List price: $103.45
  • Compression Ring
    • Ref No: 39
    • Part No: 00200008
    • Qty Req: 3
    Our price: $11.75 List price: $13.82
  • Piston Sleeve (APS71)
    • Ref No: 40
    • Part No: 04000074
    • Qty Req: 3
    Our price: $138.92 List price: $163.44
  • Diaphragm Holder Screw
    • Ref No: 41
    • Part No: 36050005
    • Qty Req: 3
    Our price: $26.73 List price: $31.45
  • Washer
    • Ref No: 42
    • Part No: 06020010
    • Qty Req: 3
    Our price: $5.65 List price: $6.65
  • Diaphragm, Buna
    • Ref No: 43
    • Part No: 18000088
    • Qty Req: 3
    Our price: $26.65 List price: $31.35
  • Pin
    • Ref No: 44
    • Part No: 30110021
    • Qty Req: 3
    Our price: $14.96 List price: $17.60
  • Snap Ring
    • Ref No: 45
    • Part No: 30200029
    • Qty Req: 6
    Our price: $0.44 List price: $0.52
  • Roller Bearing
    • Ref No: 47
    • Part No: 04370022
    • Qty Req: 1
    Our price: $59.00 List price: $69.41
  • Ring
    • Ref No: 48
    • Part No: 00090186
    • Qty Req: 1
    Our price: $1.95 List price: $2.29
  • Connecting Rod Ring
    • Ref No: 49
    • Part No: 00100021
    • Qty Req: 2
    Our price: $40.35 List price: $47.47
  • Snap Ring
    • Ref No: 50
    • Part No: 30190001
    • Qty Req: 1
    Our price: $4.53 List price: $5.33
  • Ball Bearing
    • Ref No: 51
    • Part No: 04380001
    • Qty Req: 1
    Our price: $179.27 List price: $210.91
  • Throughshaft, APS71
    • Ref No: 52
    • Part No: 00010518
    • Qty Req: 1
    Our price: $457.84 List price: $538.64
  • Oil Seal
    • Ref No: 53
    • Part No: 00190085
    • Qty Req: 1
    Our price: $22.91 List price: $26.95
  • Snap Ring
    • Ref No: 54
    • Part No: 30200002
    • Qty Req: 1
    Our price: $6.39 List price: $7.52
  • Cover
    • Ref No: 55
    • Part No: 04020141
    • Qty Req: 1
    Our price: $5.92 List price: $6.96
  • O-Ring
    • Ref No: 56
    • Part No: 12100122
    • Qty Req: 1
    Our price: $2.36 List price: $2.78
  • Oil Neck Glass
    • Ref No: 57
    • Part No: 04210015
    • Qty Req: 1
    Our price: $15.85 List price: $21.13
  • Screw
    • Ref No: 58
    • Part No: 36090002
    • Qty Req: 2
    Our price: $1.73 List price: $2.04
  • Washer
    • Ref No: 59
    • Part No: 28110004
    • Qty Req: 4
    Our price: $0.48 List price: $0.56
  • O-Ring
    • Ref No: 60
    • Part No: 12100233
    • Qty Req: 1
    Our price: $0.48 List price: $0.56
  • Crankcase
    • Ref No: 72
    • Part No: 04030115
    • Qty Req: 1
    Our price: $876.17 List price: $1,030.79
