Comet MC25 Diaphragm Pump

Comet MC25 Diaphragm Pump

Brand:
Comet
Weight:
11.0 lb
Item #
MC25

Regular price $535.40
Sale price $535.40 Regular price List Price: $957.22

Free Shipping on Qualified Orders Over $100

In stock orders placed within

ship out same day. Learn more

Earn 1,606 points with this purchase.

View full details

Collapsible content

Product Overview

Comet MC25 Diaphragm Pump

**This pump comes with a male PTO shaft output.  If you are using this pump on a gas engine you must purchase the MC25GR.**

5 gpm, 350 psi

Twin diaphragm pump with 1 3/8" 6 spline PTO shaft. Includes pressure regulator with manual dump lever and mounting rails.

Low to medium pressure diaphragm pumps with plastic (MC8/18) or anodized aluminum (MC25) bodies. Great for agricultural spraying, as well as gardening, pest control, lawn care, mold removal and insulation.

Parts breakdown

Diagram

Diagram parts

Parts list

  • Roller Bearing
    • Ref No: 1
    • Part No: 04370017
    • Qty Req: 1
    Our price: $29.13 List price: $34.27
  • Spacer
    • Ref No: 2
    • Part No: 06010235
    • Qty Req: 1
    Our price: $4.37 List price: $5.14
  • Connecting Rod Ring
    • Ref No: 3
    • Part No: 00100012
    • Qty Req: 2
    Our price: $12.71 List price: $14.95
  • Washer
    • Ref No: 4
    • Part No: 28130073
    • Qty Req: 1
    Our price: $3.96 List price: $4.66
  • Shaft
    • Ref No: 5
    • Part No: 00010291
    • Qty Req: 1
    Our price: $274.03 List price: $322.39
  • External Gear
    • Ref No: 6
    • Part No: 04090019
    • Qty Req: 1
    Our price: $186.60 List price: $219.53
  • O-Ring
    • Ref No: 7
    • Part No: 12100053
    • Qty Req: 1
    Our price: $3.39 List price: $3.99
  • Ball Bearing
    • Ref No: 8
    • Part No: 04380065
    • Qty Req: 1
    Our price: $46.84 List price: $55.10
  • Support
    • Ref No: 9
    • Part No: 30020491
    • Qty Req: 1
    Our price: $56.32 List price: $66.26
  • Oil Seal
    • Ref No: 10
    • Part No: 00190086
    • Qty Req: 1
    Our price: $9.05 List price: $10.65
  • Screw
    • Ref No: 11
    • Part No: 36090173
    • Qty Req: 4
    Our price: $0.61 List price: $0.72
  • Connecting Rod Assembly
    • Ref No: 12
    • Part No: 02050059
    • Qty Req: 1
    Our price: $94.75 List price: $111.47
  • Piston
    • Ref No: 13
    • Part No: 24090023
    • Qty Req: 2
    Our price: $65.08 List price: $76.57
  • Gudgeon Pin
    • Ref No: 14
    • Part No: 30110006
    • Qty Req: 2
    Our price: $13.70 List price: $16.12
  • Snap Ring
    • Ref No: 15
    • Part No: 30200020
    • Qty Req: 4
    Our price: $0.43 List price: $0.50
  • Piston Sleeve
    • Ref No: 16
    • Part No: 04000069
    • Qty Req: 2
    Our price: $136.25 List price: $160.29
  • Piston Diaphragm, Buna - Comet Diaphragm Pump APS41 / MC25 / MP20/30
    • Ref No: 17
    • Part No: 18000020
    • Qty Req: 2
    Our price: $15.00 List price: $17.65
  • Disc
    • Ref No: 18
    • Part No: 06020033
    • Qty Req: 2
    Our price: $11.65 List price: $13.70
  • Diaphragm Holder Screw
    • Ref No: 19
    • Part No: 36050027
    • Qty Req: 2
    Our price: $13.70 List price: $16.12
  • Screw
    • Ref No: 47
    • Part No: 36090165
    • Qty Req: 2
    Our price: $1.41 List price: $1.66
  • Pressure Accumulator for MC25 Comet Pumps
    • Ref No: 48
    • Part No: 00030011
    • Qty Req: 1
    Our price: $42.98 List price: $50.57
  • Nut
    • Ref No: 49
    • Part No: 06040063
    • Qty Req: 4
    Our price: $0.60 List price: $0.71
  • Screw
    • Ref No: 50
    • Part No: 36090162
    • Qty Req: 2
    Our price: $1.79 List price: $2.11
  • Washer
    • Ref No: 51
    • Part No: 28110016
    • Qty Req: 2
    Our price: $1.49 List price: $1.75
  • Air Valve
    • Ref No: 52
    • Part No: 36100003
    • Qty Req: 1
    Our price: $16.16 List price: $19.01
  • Gasket
    • Ref No: 53
    • Part No: 12090033
    • Qty Req: 2
    Our price: $1.00 List price: $1.18
  • Pump Head
    • Ref No: 54
    • Part No: 32180015
    • Qty Req: 1
    Our price: $82.22 List price: $96.73
  • Accumulator Diaphragm, Comet Diaphragm Pump MC25 / MP20/30
    • Ref No: 55
    • Part No: 18000033
    • Qty Req: 1
    Our price: $19.58 List price: $23.03
  • Oil Cup Cover
    • Ref No: 56
    • Part No: 18000079
    • Qty Req: 1
    Our price: $6.83 List price: $8.03
  • Pump Crankcase
    • Ref No: 57
    • Part No: 04030134
    • Qty Req: 1
    Our price: $289.28 List price: $340.33
  • Wing Nut
    • Ref No: 58
    • Part No: 12000008
    • Qty Req: 1
    Our price: $6.10 List price: $7.18
  • Hose Barb
    • Ref No: 59
    • Part No: 28000016
    • Qty Req: 1
    Our price: $6.49 List price: $7.63
  • O-Ring
    • Ref No: 60
    • Part No: 12100039
    • Qty Req: 1
    Our price: $0.81 List price: $0.95
  • Screw
    • Ref No: 62
    • Part No: 36050032
    • Qty Req: 4
    Our price: $3.21 List price: $3.78
  • U-Bolt
    • Ref No: 63
    • Part No: 04180018
    • Qty Req: 4
    Our price: $16.97 List price: $22.63
  • Plate
    • Ref No: 64
    • Part No: 24030075
    • Qty Req: 4
    Our price: $0.46 List price: $0.54
  • Plug
    • Ref No: 65
    • Part No: 32020027
    • Qty Req: 4
    Our price: $7.86 List price: $9.25
  • Plug
    • Ref No: 66
    • Part No: 32020214
    • Qty Req: 1
    Our price: $9.94 List price: $11.69
  • O-Ring
    • Ref No: 67
    • Part No: 12100052
    • Qty Req: 4
    Our price: $3.07 List price: $3.61
  • Valve Cage
    • Ref No: 68
    • Part No: 12050007
    • Qty Req: 4
    Our price: $3.04 List price: $3.58
  • Valve Spring
    • Ref No: 69
    • Part No: 18020015
    • Qty Req: 4
    Our price: $1.82 List price: $2.14
  • Valve Plate
    • Ref No: 70
    • Part No: 36040007
    • Qty Req: 4
    Our price: $2.66 List price: $3.13
  • Valve Seat
    • Ref No: 71
    • Part No: 30090023
    • Qty Req: 4
    Our price: $4.26 List price: $5.01
  • O-Ring
    • Ref No: 72
    • Part No: 12100029
    • Qty Req: 4
    Our price: $1.11 List price: $1.30
  • Check Valve
    • Ref No: 73
    • Part No: 12120004
    • Qty Req: 4
    Our price: $12.85 List price: $15.12
  • Pump Head
    • Ref No: 74
    • Part No: 32180016
    • Qty Req: 1
    Our price: $82.24 List price: $96.75
