Udor KAPPA-100/GR Diaphragm Pump

Udor KAPPA-100/GR Diaphragm Pump

Brand:
Udor
Weight:
72.0 lb
Item #
KAPPA100GR
1 1

Udor KAPPA-100/GR Diaphragm Pump

Udor KAPPA-100/GR Diaphragm Pump

Brand:
Udor
Weight:
72.0 lb
Item #
KAPPA100GR

$2,398.07
$2,398.07 List Price: $4,360.10

We're here to help!

Let us know if you need assistance finding the right spray equipment

Earn 7,194 points with this purchase.

See Details

View full details

Product Overview

26 gpm, 560 psi.

KAPPA-100 with gear reduction for use on 16-18 HP gasoline engines with 1" shafts.

UDOR KAPPA Series Pumps Are Internally Manifolded With Anodized Aluminum Construction.

Resources

Download Product Manual

Parts breakdown

Diagram

Diagram parts

Parts list

  • Retainer Ring
    • Ref No: 5
    • Part No: 000107
    • Qty Req: 2
    Our price: $61.26 List price: $73.80
  • Crankshaft (KAPPA-100, KAPPA-75)
    • Ref No: 67
    • Part No: 000256
    • Qty Req: 1
    Our price: $419.23 List price: $505.10
  • Accumulator Body
    • Ref No: 78
    • Part No: 000310
    • Qty Req: 1
    Our price: $287.67 List price: $346.60
  • SEAL
    • Ref No: 170
    • Part No: 000727
    • Qty Req: 1
    Our price: $33.29 List price: $40.10
  • Diaphragm Bolt (KAPPA-30/33/40/43/55/75/100)
    • Ref No: 240
    • Part No: 0010204
    • Qty Req: 4
    Our price: $24.90 List price: $30.00
  • Hose Barb Elbow (KAPPA-100, RO-160/320)
    • Ref No: 370
    • Part No: 020278
    • Qty Req: 1
    Our price: $29.29 List price: $35.30
  • Piston Sleeve (KAPPA-75/100)
    • Ref No: 497
    • Part No: 020624
    • Qty Req: 4
    Our price: $158.52 List price: $191.00
  • Oil Cap **Obsolete - no longer available. Must buy 603301 complete assembly**
    • Ref No: 540
    • Part No: 020898
    • Qty Req: 1
    Our price: $16.52 List price: $19.90
  • Accumulator Head
    • Ref No: 558
    • Part No: 020821
    • Qty Req: 1
    Our price: $260.05 List price: $313.30
  • Pump Body (KAPPA-100)
    • Ref No: 632
    • Part No: 020945
    • Qty Req: 1
    Our price: $789.09 List price: $950.70
  • Pump Body (Throughshaft Version)
    • Ref No: 633
    • Part No: 020947
    • Qty Req: 1
    Our price: $751.65 List price: $905.60
  • Ball Bearing (KAPPA-30/40/55/75/100, RO-70)
    • Ref No: 698
    • Part No: 021401
    • Qty Req: 1
    Our price: $264.94 List price: $319.20
  • Bearing
    • Ref No: 701
    • Part No: 021405
    • Qty Req: 1
    Our price: $145.57 List price: $175.40
  • Air Valve Cap (KAPPA-100/120, RO-70/110/160)
    • Ref No: 747
    • Part No: 021801
    • Qty Req: 1
    Our price: $3.57 List price: $4.30
  • Retainer Washer (KAPPA-30/40/55/75/100)
    • Ref No: 794
    • Part No: 030114
    • Qty Req: 4
    Our price: $14.49 List price: $17.19
  • Washer (KAPPA-75/100)
    • Ref No: 804
    • Part No: 030132
    • Qty Req: 2
    Our price: $17.10 List price: $20.60
  • Washer (KAPPA-75/100)
    • Ref No: 832
    • Part No: 030251
    • Qty Req: 2
    Our price: $17.10 List price: $20.60
  • Nut
    • Ref No: 845
    • Part No: 030301
    • Qty Req: 8
    Our price: $2.25 List price: $2.70
  • Self-Locking Nut
    • Ref No: 871
    • Part No: 030404
    • Qty Req: 2
    Our price: $2.99 List price: $3.60
  • Manifold Cover (KAPPA-100)
    • Ref No: 884
    • Part No: 050187
    • Qty Req: 1
    Our price: $101.10 List price: $121.80
  • Flange (KAPPA-75/100)
    • Ref No: 924
    • Part No: 050169
    • Qty Req: 1
    Our price: $131.13 List price: $158.00
  • Flange (KAPPA-75/100)
    • Ref No: 925
    • Part No: 050170
    • Qty Req: 1
    Our price: $197.46 List price: $237.90
  • Gasket for Udor Gear Reduction
    • Ref No: 977
    • Part No: 060205
    • Qty Req: 1
    Our price: $4.40 List price: $5.30
  • Suction Nut
    • Ref No: 1042
    • Part No: 060425
    • Qty Req: 1
    Our price: $17.51 List price: $21.10
  • Aluminum Gasket
    • Ref No: 1072
    • Part No: 060509
    • Qty Req: 1
    Our price: $2.08 List price: $2.50
  • Air Valve Assembly
    • Ref No: 1122
    • Part No: 060816
    • Qty Req: 1
    Our price: $23.57 List price: $28.40
  • Piston Diaphragm Buna-N (Opt.)
    • Ref No: 1299
    • Part No: 090313
    • Qty Req: 4
    Our price: $33.37 List price: $40.20
  • Accumulator Diaphragm
    • Ref No: 1301
    • Part No: 090316
    • Qty Req: 1
    Our price: $46.90 List price: $56.50
  • O-Ring
    • Ref No: 1381
    • Part No: 110127
    • Qty Req: 8
    Our price: $3.32 List price: $4.00
  • O-Ring
    • Ref No: 1382
    • Part No: 110129
    • Qty Req: 10
    Our price: $2.99 List price: $3.60
  • O-Ring
    • Ref No: 1395
    • Part No: 110148
    • Qty Req: 1
    Our price: $7.97 List price: $9.60
  • O-Ring
    • Ref No: 1398
    • Part No: 110142
    • Qty Req: 1
    Our price: $3.32 List price: $4.00
  • O-Ring
    • Ref No: 1408
    • Part No: 110163
    • Qty Req: 1
    Our price: $14.36 List price: $17.30
  • O-Ring
    • Ref No: 1421
    • Part No: 110188
    • Qty Req: 1
    Our price: $11.62 List price: $14.00
  • O-Ring
    • Ref No: 1434
    • Part No: 1101D1
    • Qty Req: 1
    Our price: $6.73 List price: $8.10
  • Mounting Rail
    • Ref No: 1460
    • Part No: 120237
    • Qty Req: 2
    Our price: $57.69 List price: $69.50
  • Piston
    • Ref No: 1578
    • Part No: 120518
    • Qty Req: 4
    Our price: $120.03 List price: $144.60
  • Valve Assembly for Udor Diaphragm Pumps
    • Ref No: 1702
    • Part No: 600601
    • Qty Req: 8
    Our price: $33.94 List price: $40.90
  • Head Assembly
    • Ref No: 1721
    • Part No: 601706
    • Qty Req: 4
    Our price: $151.31 List price: $182.30
  • Oil Reservoir Assembly
    • Ref No: 1740
    • Part No: 603301
    • Qty Req: 1
    Our price: $78.19 List price: $94.20
  • Piston/Rod Assembly
    • Ref No: 1801
    • Part No: 601529
    • Qty Req: 4
    Our price: $216.21 List price: $260.50
  • 6031.02 Pulsation Dampener
    • Ref No: 1804
    • Part No: 603102
    • Qty Req: 1
    Our price: $459.47 List price: $629.40
  • Washer
    • Ref No: 1843
    • Part No: 140307
    • Qty Req: 2
    Our price: $1.67 List price: $2.00
  • Washer
    • Ref No: 1845
    • Part No: 140310
    • Qty Req: 6
    Our price: $1.67 List price: $2.00
  • Connecting Rod Pin
    • Ref No: 1967
    • Part No: 150207
    • Qty Req: 4
    Our price: $30.21 List price: $36.40
  • Snap Ring
    • Ref No: 2051
    • Part No: 150615
    • Qty Req: 8
    Our price: $2.25 List price: $2.70
  • Connecting Rod
    • Ref No: 2152
    • Part No: 151919
    • Qty Req: 4
    Our price: $80.67 List price: $97.20
  • Oil Plug
    • Ref No: 2251
    • Part No: 160302
    • Qty Req: 1
    Our price: $8.47 List price: $10.20
  • Head Plug
    • Ref No: 2268
    • Part No: 160332
    • Qty Req: 9
    Our price: $9.13 List price: $11.00
  • Bolt
    • Ref No: 2473
    • Part No: 180454
    • Qty Req: 8
    Our price: $2.66 List price: $3.20
  • Bolt
    • Ref No: 2583
    • Part No: 180505
    • Qty Req: 4
    Our price: $2.99 List price: $3.60
  • Bolt
    • Ref No: 2589
    • Part No: 180531
    • Qty Req: 2
    Our price: $2.25 List price: $2.70
  • Bolt
    • Ref No: 2593
    • Part No: 180514
    • Qty Req: 8
    Our price: $4.56 List price: $5.50
  • Bolt
    • Ref No: 2594
    • Part No: 180524
    • Qty Req: 6
    Our price: $2.33 List price: $2.80
  • Bolt
    • Ref No: 2603
    • Part No: 180512
    • Qty Req: 12
    Our price: $3.57 List price: $4.30
  • Washer
    • Ref No: 7671
    • Part No: 140309
    • Qty Req: 12
    Our price: $1.67 List price: $2.00
  • Head Bolt (Hex Head - New Style)
    • Ref No: 7948
    • Part No: 180445
    • Qty Req: 20
    Our price: $4.98 List price: $6.00
  • Piston Diaphragm Desmopan (Std.)
    • Ref No: 8117
    • Part No: 090338
    • Qty Req: 4
    Our price: $50.22 List price: $60.50
